Manufacturer |
Rockwell Automation |
Supply Current |
15mA @ 24V dc |
Keyswitch position |
6 |
Enclosure type rating |
None (open-style) |
Dimensions |
56 x 12 x 75.5 mm (2.2 x 0.47 x 2.97 in.) |
External DC voltage range |
10-28.8V dc |
External dc voltage, nominal |
24VDC |
Thermal Dissipation |
2.5 BTU/hr maximum @ 28.8V dc |
Power Dissipation |
0.75W maximum @ 28.8V dc |
Module Location |
1734-TB, 1734-TBS, 1734-TOP, or 1734-TOPS wiring base assembly |
Indicators |
1 green/red module status indicator, logic side 1 green/red network status indicator, logic side 2 green TXD, RXD status indicators, logic side |
No. of inputs |
One (1) |
Brand |
Allen-Bradley |
Part Number/Catalog No. |
1734-232ASC |
Module Type |
POINT I/O ASCII communication module |
Key Switch Position |
2 |
Product Family |
1734 POINT I/O |
Voltage Range |
10-28.8 volts DC |
Supported Protocol |
ASCII |
No of application ports |
One (1) Full-Duplex port |
UPC |
10612598283702 |
Communication speed |
9600, 1200, 2400, 4800, 19.2k, and 38.4k communication speeds |
Serial Character Framing |
7N2, 7E1, 7O1, 8N1, 8N2, 8E1, 8O1, 7E2, 7O2 |
