Manufacturer |
Rockwell Automation |
Power supply, redundant |
1756-PA75R, 1756-PB75R, 1756-PSCA2 |
Power supply, standard |
1756-PA72/C, 1756-PA75/B, 1756-PB72/C, 1756-PB75/B, 1756-PC75/B, 1756-PH75/B |
Chassis |
1756-A4, 1756-A7, 1756-A10, 1756-A13, 1756-A17 |
Operating Temperature |
32-140 Fahrenheit (0-60 Celsius) |
Dimensions |
5.51 x 4.41 x 5.71 inches |
Communication Cable |
1786-RG6 quad shield RG6 coaxial cable |
Enclosure |
Open Type |
Power Dissipation (Max) |
5.5 Watts |
Isolation Voltage |
30 Volts Continuous |
Backplane Current (24 Volts DC) |
1.7 milliamps |
Backplane Current (5.1 Volts DC) |
970 milliamps |
No. of Ports |
Two (2) ControlNet ports |
Brand |
Allen-Bradley |
Part Number/Catalog No. |
1756-CNBR |
Series |
ControlLogix |
Module Type |
ControlNet communication module |
Location |
Chassis |
Current Draw at 5.1 Volts DC |
970 Miliamperes |
Current Draw at 24 Volts DC |
1.7 Miliamperes |
ControlNet Rate of Communication |
5 Mbps |
Logix Communication Connections |
40-48 |
Max Connections Supported |
64 |
Max Number of Nodes |
99 |
Slot Width |
1 |
Weight |
0.64 lbs (0.293 kg) |
UPC |
10612598174086 |
