Manufacturer |
Rockwell Automation |
Dimensions |
17.5 x 14.5 x 13.7 cm (6.9 x 5.7 x 5.4 in.) |
Chassis Compatibility |
1756-A4, 1756-A7, 1756-A10, 1756-A13, 1756-A17 |
Hold Up time |
2 cycles @ 60 Hz; 2 cycles @ 50 Hz |
Annunciator Power |
240V AC 50/60 Hz, 240V DC, 50 mA, resistive only |
Output Power |
75 W @ 0…60 °C (32…140 °F) |
Current Capacity |
1.5 A at 1.2VDC; 4A at 3.3VDC; 13 A at 5.1VDC and 2.8 A at 24VDC |
Max Inrush Current |
20 Amperes |
Isolation Voltage |
250V (continuous), Reinforced Insulation Type, Power Input to Backplane, Power Input to Annunciator, Annunciator to Backplane Type tested at 3250V DC for 60 s |
Input Voltage Range |
85-264VAC |
Nom Input Voltage |
120/240VAC |
Brand |
Allen-Bradley |
Part Number/Catalog No. |
1756-PA75R |
Series |
ControlLogix |
Module Type |
Redundant Power Supply |
Weight |
1.45 kg (3.2 lb) |
Input Voltage |
120-220 Volts AC |
Voltage Range |
85-265 Volts AC |
Input Power |
115 Watts |
Input Frequency |
47-63 Hertz |
Power Output |
75 Watts at 60 Celsius |
Chassis |
Series B |
Location |
Panel Mounted |
Operating Temperature |
32-140 Fahrenheit (0-60 Celsius) |
Enclosure |
None |
UPC |
10612598274229 |
UNSPSC |
32151706 |
