Manufacturer |
Rockwell Automation |
No. of Inputs |
Eight (8) channels |
Isolation rating |
Verified by one of the following dielectric tests: 1200V ac for 1 sec. or 1697V dc for 1 sec. 75V dc working voltage (IEC Class 2 reinforced insulation) |
Backplane Current, 24VDC |
0 mA |
Backplane Current, 5.1VDC |
50 mA |
Signal Delay, ON transition |
8 ms |
Off-state Current, max. |
1.5 mA |
ON-state Current, min. |
2.0 mA min. at 10VDC; 8.0 mA nominal at 24VDC; 12.0 mA max. at 30VDC |
Input voltage range |
10-30 VDC |
Nominal input voltage |
24VDC |
Channels per group: |
Eight (8) |
No. of groups |
One (1) isolated groups |
Brand |
Allen-Bradley |
Part Number/Catalog No. |
1762-IQ8 |
Series |
MicroLogix |
Module Type |
Discrete input module |
Input Power |
24 Volts DC |
Inputs |
(8) Sink and Source |
Operating Voltage Range |
10 to 30 Volts DC |
Heat Dissipation |
3.7 Watts |
UPC |
10612598207203 |
