Manufacturer |
Rockwell Automation |
Part Number/Catalog No. |
1762-IT4 |
Filter frequency: |
10 Hz; 50 Hz; 60 Hz; 250 Hz; 500 Hz; 1 kHz |
Module resolution: |
15-bits |
Compatible millivolt signals: |
-50…50 mV and -100…100 mV |
Compatible Thermocouple sensors: |
Type J, Type K, Type T, Type E, Type R, Type S, Type B, Type N, and Type C |
Number of Inputs: |
Four (4) |
Product Description: |
Thermocouple input module |
Channel update time: |
303 ms; 63 ms; 53 ms; 15 ms; 9 ms; 7 ms |
Brand |
Allen-Bradley |
Enclosure |
Open-type |
Mounting: |
DIN Rail |
Operating Temperature: |
0 to 55 C (32 to 131 F) |
Storage Temperature: |
-40 to 85 C (-40 to 185 F) |
Converter Type |
Delta-Sigma |
Vibration: |
5g @ 10 to 500 Hz |
Operating Shock: |
30 g |
Manufacturer |
Rockwell Automation |
Product Line |
MicroLogix 1200 |
1762- IT4 |
Product Family: |
Module Type |
Thermocouple/mV Input |
Inputs |
4 Channels plus 1 CJC Sensor |
MicroLogix 1200 |
Product Type: |
Input Filtering |
Programmable Notch Filter |
Thermocouple / milivolt Input Module |
No. of Inputs: |
4 |
Compatible Controllers: |
MicroLogix 1200 |
Sensors supported: |
Calibration |
Autocalibrates |
J, K, T, E, R, N, S, B, N, C |
millivolt signal: |
Power Supply Distance Rating |
6 |
+/- 50mV and +/-100mV |
CJC sensor: |
Heat Dissipation |
1.5 Total Watts |
Dimensions |
3.54 inch x 3.43 inch x 1.58 inch |
Included |
Module Resolution |
UPC |
10611320861669 |
15-bits plus sign |
Converter type |
Delta-Sigma |
Current draw @ 5.1V: |
40 mA |
Current draw @ 24V: |
50 mA |
Heat dissipation, max: |
1.5W |
Calibration: |
Performed during power-up; programmable |
CJC sensor accuracy: |
UPC |
10611320861669 |
