Manufacturer |
Rockwell Automation |
Power Supply Usage |
40W |
Power supply inrush current |
120V ac: 25A for 8 ms; 240V ac: 40A for 4 ms |
Ambient Operating Temp |
0 to 55 degrees Celsius |
Supported Protocols |
DF1, DH-485, ASCII, MODBUS |
Communication Ports |
One (1) 8-Pin mini-DIN serial port; |
Load Current |
10A, minimum |
Mechanical Cycles |
20000000 |
Relay Contact Rating |
24-125VDC; 120-240VAC |
Output Circuit Type |
Relay; FET |
Input Circuit Type |
24 VDC sink / source |
No. of Outputs |
Five (5) relay; Four (4) 24V dc FET; (1) high-speed 24V dc FET |
No. of Inputs |
Ten (10) 24V dc; (4) fast 24V dc |
Power Supply |
24VDC |
Brand |
Allen-Bradley |
Part Number/Catalog No. |
1762-L24BXB |
Dimensions |
Height: 90 mm 104 mm (with DIN latch open); Width: 160 mm; Depth: 87 mm |
Shipping Weight |
2.4 pounds |
Series |
MicroLogix 1200 |
Module Type |
Programmable Controller |
Inputs |
(10) 24V DC and (4) Fast 24V DC |
Outputs |
(5) Relay, (4) 24V DC FET, (1) High-Speed 24V DC FET |
Input Power |
24V DC |
Power Supply Output |
400 or 350 milliamps |
Operating Frequency |
0-20 kilohertz |
UPC |
10612598279309 |
UNSPSC |
32151705 |
