Manufacturer |
Rockwell Automation / Allen-Bradley |
Brand |
Allen-Bradley |
Product Family: |
Compact I/O |
Part Number/Catalog No. |
1769-OB16 |
Product Type: |
Discrete Output Module |
Product Line |
CompactLogix |
Module Type |
DC Output Module |
No. of Outputs: |
16 |
Input Type |
Digital Output |
No. of Groups: |
1 |
Power Supply Distance Rating |
8 |
Communication Cable |
16-Point |
Voltage Category |
24V DC source |
Shipping Weight |
2 lbs |
Shipping Dimensions |
8 x 8 x 5 in |
Operating Voltage range: |
20.4…26.4V DC |
Current per point: |
0.5 A @ 60 °C (140 °F) 1.0 A @ 30 °C (86 °F) |
Power |
24 Volts DC |
Output delay, On: |
0.1 ms |
Output delay, Off: |
1.0 ms |
Series |
A and B |
Series |
A and B |
Bus Current draw, max: |
200 mA |
Heat Dissipation: |
2.11 W |
Wire Size (Solid) |
22-14 AWG |
Mounting: |
DIN rail or panel mount |
UPC |
10662468992869 |
Terminal Block: |
1769-RTBN18 (1 per kit) |
UNSPSC |
32151705 |
Power Supply: |
1769-PA2, 1769-PB2, 1769-PA4, 1769-PB4 |
